Rivacold outdoor unit NF CO2NNEXT 100 R744 400V
Description
CO2nnext is a range of condenser units and split systems that use the RBDC variable speed transcritical hermetic scroll compressor for normal cooling and deep freeze applications. Thanks to a new generation of CO2 controllers, this simple-to-install system is designed for connecting up to 5 ...
CO2nnext is a range of condenser units and split systems that use the RBDC variable speed transcritical hermetic scroll compressor for normal cooling and deep freeze applications. Thanks to a new generation of CO2 controllers, this simple-to-install system is designed for connecting up to 5 units. Rivacold guarantees energy efficiency, eco-sustainability and perfect food preservation.
Features
Compact CO2 condenser units
- Hermetic scroll compressor, BLDC motor
- Self-supporting housing made of galvanised steel with epoxy powder coating.
- Medium-temperature and low-temperature applications (MT 2.5 - 8.2 kW at t0 -10 °C/tu +32 °C; LT 2.2 / 6.7 kW t0 -35 °C/tu +32 °C)
- With fluid ...
Compact CO2 condenser units
- Hermetic scroll compressor, BLDC motor
- Self-supporting housing made of galvanised steel with epoxy powder coating.
- Medium-temperature and low-temperature applications (MT 2.5 - 8.2 kW at t0 -10 °C/tu +32 °C; LT 2.2 / 6.7 kW t0 -35 °C/tu +32 °C)
- With fluid collection (hp = 80 bar)
- With fluid super-cooler
- Operating pressure up to HP = 120 bar / LP = 60 bar
- Integrated gas cooler with EC fan motor
- Fan motors comply with ErP regulations (Regulation EU 327/2011)
- With dryer filter, inspection glass and safety pressure switch
- Low operating noise and efficient operation
- Shut-off valves in the suction and fluid lines
- Solder connections
- Integrated controller with master switch
- Easy to install
- Optional water cooling (on request)
- Optional noise insulation (on request)
Advantages ...
- ... of CO2 as a refrigerant:
- Non-toxic, non-flammable
- Global warming potential (GWP100) = 1
- Ozone depletion potential (ODP) = 0
- High volumetric cooling capacity
Accessories / Replacement parts
-
Check valve 120bar
-
Connection cable for pressure switch / pressure monitor
-
Connection cable for pressure transmitter
-
Control / display
-
Control
-
Expansion valve electronic
-
Inverter
-
Pressure monitor
-
Pressure transmitter 120bar
-
Pressure transmitter 60bar
-
Replacement compressor
-
Temperature sensor
-
Ventilation unit
Technical data
with EC motors
1) Electrical performance data based on t0=-10 °C and tu= +32 °C (preliminary data from 12/2018)
